Computer-Aided Engineering Drawing covers the essentials of computer-aided engineering drawing with the help of step-by-step explanation of the generic process employed by standard engineering drawing software. The author adopts an interactive approach to convey the principles of freehand sketching, orthographic projection of points, straight lines, plane surfaces and sections of solids and illustrates the development of lateral surfaces of solids and isometric projections using BIS SP: 46-2003 standards.
S Trymbaka Murthy is a professor in the Department of Mechanical Engineering,
Sir M. Visvesvaraya Institute of Technology, Bengaluru. Earlier, he had taught at Siddaganga Institute of Technology, Tumkur. A dedicated teacher with over four decades of teaching experience, Prof. Murthy received his BSc and BE degrees from Yuvaraja’s College and Sri Jayachamarajendra College of Engineering, Mysore, respectively, and his master's degree in machine design from UVCE, Bengaluru.
the Fourth Edition
the First Edition
Symbols and Notations
Recommended by BIS
3. Elements And Principles of Orthographic Projection
4. FreeHand Sketching
5. Projections of Points
6. Projections of Straight Lines
7. Projections of Plane Surfaces
8. Projections of Solids
9. Sections and Section Planes
10. Development of Lateral Surfaces of Solids
11. Isometric Projection
